33' x 6'7" Tri Axle Air Bag Aluminium Tipper for sale
1 of 3
$121,825
inc. GST
REF: J/N: 11320
NEW
Description
Axles: YORK 5” Round Road Baron Axles – Enclosed ‘S’ Cams – 10 Stud Hubs – Grease Filled 285pcd
Suspension: YORK 9’1” Spread Duratrac Air Bag Suspension with AirTec Weight Gauge & Dump Valve
Braking System: Air Brake Corp LSV Brake Kit – Push/Pull Coupling – with Yard Release Button Air Lines in Front & Behind King Pin
Main Beam: 100 x 16mm Top Flange
100 x 20mm Bottom Flange
5mm Webb
Body: 5mm Sides – Aluminium – Nil Rope Rail
6mm Floor – Aluminium – PVC Guards over Tri Group
Skid Plate: 10mm thick with 50mm Road Train Rated bolt in King Pin set @ 720 / 1020 / 1370 from front of Trailer
Tyre Carrier: Dual bolt on to underside of Trailer
Hoist: 5 Stage 50 tonne JOST Hoist
Toolbox: One (1) Steel Lockable
Watertank: One (1) 60 Litre Alloy
Tailgate: One-Way Tailgate – Air Opening switch on Rear Post, Safety Locks & Spreader Chains, Aluminium Grain Door & Chute, Grain Seal
Lights: All HELLA L.E.D. Lights
10 x L.E.D. Clearance Lights on Tub
2 x L.E.D. Jumbo Lights at Rear + Top of Tail Gate
2 x L.E.D. Number Plate Lights
2 x Work Lights at Top of Tailgate with Switch on Rear Post
6mm Wiring
Legs: JOST Two Speed Legs with Pad Feet
Tyres: 11R Double Coin GL71 Tubeless Tyres on 13 x 10-Stud Proforge Aluminium Machine Finished Tubeless 285pcd
Roll Tarp: Academy Tarp PVC Roll Top Tarp with 3 RHS X-Bows (Manual Tarp Handle) Alloy Pelmets, Ground Operated Swing Away Ridge Pole, Grain Flap Top LHS
Ringfeder: Ringfeder Bracket inc Air, Electrical & 50mm Ringfeder Coupling. Manual Diverter Valve with Hydraulic Hose to Rear
Paint: Painted to the colour of your choice in 2-Pak – Subframe only: Chassis: Red, Body: Red / White Wrap, Tarp: Red
Sundries: Hydraulic Hose to front with 1” Tema Coupling
Front board ladder with steps on hoist well
PVC Guards over Tri-Group
Fold Down Aluminium Ladder on Rear Tail Gate
Access Door in Front Wall
Aluminium Scraper with storage on legs
Fold Down Road Train & Long Vehicle Signs
Full Width Rubber Mud Flap in Front of Legs
Road Train & B Train Labels
Suspension: YORK 9’1” Spread Duratrac Air Bag Suspension with AirTec Weight Gauge & Dump Valve
Braking System: Air Brake Corp LSV Brake Kit – Push/Pull Coupling – with Yard Release Button Air Lines in Front & Behind King Pin
Main Beam: 100 x 16mm Top Flange
100 x 20mm Bottom Flange
5mm Webb
Body: 5mm Sides – Aluminium – Nil Rope Rail
6mm Floor – Aluminium – PVC Guards over Tri Group
Skid Plate: 10mm thick with 50mm Road Train Rated bolt in King Pin set @ 720 / 1020 / 1370 from front of Trailer
Tyre Carrier: Dual bolt on to underside of Trailer
Hoist: 5 Stage 50 tonne JOST Hoist
Toolbox: One (1) Steel Lockable
Watertank: One (1) 60 Litre Alloy
Tailgate: One-Way Tailgate – Air Opening switch on Rear Post, Safety Locks & Spreader Chains, Aluminium Grain Door & Chute, Grain Seal
Lights: All HELLA L.E.D. Lights
10 x L.E.D. Clearance Lights on Tub
2 x L.E.D. Jumbo Lights at Rear + Top of Tail Gate
2 x L.E.D. Number Plate Lights
2 x Work Lights at Top of Tailgate with Switch on Rear Post
6mm Wiring
Legs: JOST Two Speed Legs with Pad Feet
Tyres: 11R Double Coin GL71 Tubeless Tyres on 13 x 10-Stud Proforge Aluminium Machine Finished Tubeless 285pcd
Roll Tarp: Academy Tarp PVC Roll Top Tarp with 3 RHS X-Bows (Manual Tarp Handle) Alloy Pelmets, Ground Operated Swing Away Ridge Pole, Grain Flap Top LHS
Ringfeder: Ringfeder Bracket inc Air, Electrical & 50mm Ringfeder Coupling. Manual Diverter Valve with Hydraulic Hose to Rear
Paint: Painted to the colour of your choice in 2-Pak – Subframe only: Chassis: Red, Body: Red / White Wrap, Tarp: Red
Sundries: Hydraulic Hose to front with 1” Tema Coupling
Front board ladder with steps on hoist well
PVC Guards over Tri-Group
Fold Down Aluminium Ladder on Rear Tail Gate
Access Door in Front Wall
Aluminium Scraper with storage on legs
Fold Down Road Train & Long Vehicle Signs
Full Width Rubber Mud Flap in Front of Legs
Road Train & B Train Labels
Listing Details
Download Brochure
| Price | $121,825 |
|---|---|
| Type | Dealer New |
| Model | All models |
| State | SA |
| Dealer Stock # | J/N: 11320 |
Further Details
| Tipper Features | |
|---|---|
| Body Type | Aluminium |
Email Enquiry
Seller Details
| Name: | Freightmaster Semi Trailers |
|---|---|
| State: | SA |
| Suburb: | Burton |
| Postcode: | 5110 |
