Description
Axles: YORK 5" Round Road Baron Axles - 10-Stud 285pcd Hubs - Grease filled
Suspension: YORK 10'1" Spread Duratrac Air Bag (360 Ride Height) with Air-Tec Weight Gauge
Braking System: Air Brake Corp Brake Kit with LSV - Push/Pull Couplings & Yard Release Button
Main Beam: 100 x 16mm Top Flange
100 x 20mm Bottom Flange
5mm Thick Webb, 8mm Thick Front Webb
Coaming: 125TFB with 100TFB 'X' members @ 600 centres (gate pockets)
Floor: 3mm Checker Plate with 9 Floor Runners - 20mm floor drop
Skid Plate: 10mm thick with Bolt in 50mm Road Train rated King Pin @1400mm
Toolbox: Two (2) Steel Lockable Toolbox 1200 x 550 x 650 with Twistlocks
Tyre Carrier: Dual bolt on to underside of Trailer
Water tank: One (1) 60 litre Plastic with Soap Bottle
Lights: All HELLA L.E.D. Lights
12 x L.E.D. Clearance Lights per side with Centre Turning Flasher
2 x L.E.D. Jumbos at Rear
2 x L.E.D. Number Plate Lights
4mm Wiring
Legs: JOST A520 Two-Speed Legs with Pad Feet
Gates: 6ft High Load Racks & Full Set of RHS Gates
Gate Carrier: Bolt on to suit above Gates with 2 Straps
Ringfeder: Bracket only
Twistlocks: 4 x Rows 1 x 40' & 2 x 20' Containers
Tyres: Double Coin GL71 Advance Tubeless Tyres on 13 x 10-Stud ProForge Machine Finished Tubeless Rims (285pcd)
Paint: Sandblasted & Painted to the colour of your choice in 2-Pak: BLUE
Sundries: Timber Box behind Tri Group
8 Bolster Pockets only (No Bolsters)
PVC Guards over Tri Group
