FOR HIRE DEVELON DTL26 TRACKED SKID STEER LOADER

FOR HIRE DEVELON DTL26 TRACKED SKID STEER LOADER

Contact us for further information on availability and rates

1800 SEM HIRE

bookings@semhire.com.au

_______________________

The DEVELON DTL26 Tracked Skid Steer Loader delivers exceptional power, stability, and versatility, making it the ideal machine for earthmoving, landscaping, construction, demolition, and site preparation. Its rubber track undercarriage provides excellent traction and low ground pressure, allowing it to work efficiently on soft, uneven, and challenging terrain while minimising surface disturbance.

Powered by a high-performance diesel engine, the DTL26 offers impressive lifting capacity, outstanding breakout force, and smooth hydraulic performance to maximise productivity on every job. The spacious operator's cabin is designed for comfort and visibility, with ergonomic controls that reduce operator fatigue during long working days.

Compatible with a wide range of attachments, including buckets, forks, augers, trenchers, and more, the DEVELON DTL26 is a highly versatile machine capable of tackling countless applications across civil, agricultural, and commercial projects.

Features:

Rated Operating Capacity: Approx. 1,180 kg

Powerful turbo diesel engine

High-flow hydraulic performance

Rubber track undercarriage for superior traction

Enclosed air-conditioned cabin

Joystick controls with excellent operator visibility

Quick hitch for fast attachment changes

Ideal for construction, landscaping, demolition, agriculture, and material handling

Available now for short-term and long-term hire. Contact us today for competitive hire rates and availability.

Make DEVELON

Model DTL26

Emissions certification

Number of cylinders 4

Rated power, gross (hp per SAE J1995) 72.7 PS (53.5 kW) @ 2600 rpm

Rated power, net (hp per SAE J1349) 72.7 PS (53.5 kW) @ 2600 rpm

Max. torque, net (SAE J1995) 280 Nm @ 1,600 rpm

Displacement 2,392 cc

Bore and stroke 90 x 94 mm

Starter 12 V x 3.3 kW

Battery 12 V, 100 AH

Asperation

Alternator 12 V, 90 A

Air cleaner Powercore

Aftertreatment DOC (Diesel Oxidation Catalyst)

DTL26

A Tumbler distance 59.1 (1502 mm)

B Overall length of track 78.8 (2002 mm)

C Length (without bucket) 120.1 (3052 mm)

D Length (bucket on ground) 153.1 (3891 mm)

E Max. reach (arms parallel to ground) 61.3 (1558 mm)

F Bucket pin reach at max. lift 22.2 (566 mm)

G Reach at max. lift and dump 43.8 (1114 mm)

H Ground clearance 8.8 (226 mm)

I Height to top of cab 83.3 (2116 mm)

J Max. overall height 162.8 (4137 mm)

K Bucket pin height at max. lift 123.8 (3145 mm)

L Clearance at max. lift and dump 89.9 (2284 mm)

M Cabin height above house

400 mm shoe 71.6 (1821 mm)

450 mm shoe 74.8 (1901 mm)

N Track gauge 59 (1501 mm)

O Bucket width (factory bucket) 72 (1829 mm)

P Departure angle 32

Q Rollback angle 25

R Rack back angle at max. height 86

S Max. dump angle 47.5

T Turning radius from center, rear 68.7 (1747 mm)

U Turning radius from center, coupler 60.5 (1539 mm)

V Turning radius from center, bucket 92.7 (2356 mm)

MACHINE DIMENSIONS

DRIVE SYSTEM

Travel speed [low high] 9.5 / 14 km/h (FULL OPT.)

Max. traction force (drawbar pull) 45.5 / 30.0 kN

REFILL CAPACITIES

Fuel tank 9.4 kg (92L)

DEF tank

Cooling system (radiator capacity) 40 kg

Engine oil 14.6L

Hydraulic tank 30(26.5)L

Hydraulic system

HYDRAULICS

Main pump (STD) 91 Liter/min @ 2600 rpm

Main pump (high) (US30, US31) 117 Liter/min @ 2600 rpm

Pressure (STD) 241 bar

Pressure (high) (US30, US31) 280bar

ENVIRONMENT

Sound level (2000/14/EC) 100.6 dB(A)

Cabin sound level (ISO 6396) 75 dB(A)
